Quabbin Multiconductor RS-232, AWM 2464 – 22 AWG, 15 conductor, unshielded, PVC, Chrome Gray
Part Number:
7165
Alpha Equals Part Number:
1181/15C
RoHS Compliant:
Yes
Jacket Color: Chrome Gray
Colors shown are a representation only. If you require color matching please contact us direct.
Construction Details
AWG:
22
Solid/Stranded:
Stranded
Stranded Copper:
7/30
Insulation:
Semi-Rigid PVC, .010"
Shield:
No
Jacket Type:
PVC
Jacket Color:
Chrome Gray
Overall Diameter:
.290"
Physical Properties
Temp Max.:
60 & 80
Temp Min.:
-20
Voltage Rating Max.:
300
