Quabbin Multipair Data & Computer Interconnect, AWM 2464 – 20 AWG, 2 pair, shielded, PVC, Chrome Gray

Part Number:
6151
Belden Equals Part Number:
9402
RoHS Compliant:
Yes
Jacket Color: Chrome Gray
Colors shown are a representation only. If you require color matching please contact us direct.

Construction Details

Pair Count:
2
AWG:
20
Solid/Stranded:
Stranded
Stranded Copper:
7/28
Insulation:
Semi-Rigid PVC, .010"
Shield:
Yes
Jacket Type:
PVC
Jacket Color:
Chrome Gray
Overall Diameter:
.225"
Other Details:
Drain

Ratings and Approvals

CSA AWM FT4
CM
RoHS Compliant:
Yes

Physical Properties

Temp Max.:
60 & 80
Temp Min.:
-20
Voltage Rating Max.:
300
