Quabbin Multipair RS-485, AWM 2448 – 24 AWG, 1 pair, shielded, PVC, Chrome Gray
Part Number:
8302
RoHS Compliant:
Yes
Jacket Color: Chrome Gray
Colors shown are a representation only. If you require color matching please contact us direct.
Construction Details
Pair Count:
1
AWG:
24
Solid/Stranded:
Stranded
Stranded Copper:
7/32
Insulation:
Polyethylene, .025"
Shield:
Yes
Jacket Type:
PVC
Jacket Color:
Chrome Gray
Overall Diameter:
.238"
Other Details:
Drain
Braid
Physical Properties
Temp Max.:
60 & 75
Temp Min.:
-20
Voltage Rating Max.:
300
